RK3568 平台 RC522 RFID 驱动开发全解析

一、引言
二、硬件连接

1. RC522 模块引脚说明
2. RK3568 与 RC522 的连接
3. 硬件注意事项

三、设备树配置
四、内核驱动开发
五、调试与验证
六、参考资料

一、引言

RFID 技术在物联网、门禁系统、支付终端等领域有着广泛应用。RC522 作为一款高集成度的 RFID 读写模块，支持 ISO/IEC 14443A/MIFARE 协议，可轻松实现 13.56MHz 频段的近场通信。本文将详细介绍如何在 RK3568 开发板上开发 RC522 的驱动程序，实现 RFID 卡片的读写功能。

二、硬件连接

1. RC522 模块引脚说明

RC522 模块共有 8 个引脚，常用的 6 个引脚功能如下：

引脚名称 功能描述
SDA SPI 片选信号
SCK SPI 时钟信号
MOSI SPI 主出从入信号
MISO SPI 主入从出信号
IRQ 中断引脚
GND 接地
RST 复位引脚
3.3V 电源（3.3V）

用于检测不同接口类型的连接方案

2. RK3568 与 RC522 的连接

RK3568共接6个引脚对应如下：

RC522引脚 RK3568引脚 RK3568GPIO引脚复用
SDA SPI0_CS0_M1 GPIO2_D2
SCK SPI0_CLK_M1 GPIO2_D3
MOSI SPI0_MOSI_M1 GPIO2_D1
MISO SPI0_MISO_M1 GPIO2_D0
IRQ
GND 接地
RST
3.3V 电源（3.3V）

3. 硬件注意事项

RC522 工作电压为 3.3V，不可直接连接 5V 电源，否则会损坏模块。
之前用的杜邦线过长导致通信异常，后来通过将杜邦线裁剪到3-5cm才通信成功。
RST 引脚可连接到 GPIO，以便软件控制 RC522 的复位操作。

三、设备树配置

在 Linux 系统中，设备树（Device Tree）是描述硬件设备信息的关键文件。我们需要在 RK3568 的设备树中添加 RC522 的节点配置。

/home/chenmy/rk356x/RK356X_Android11.0/kernel/arch/arm64/boot/dts/rockchip/rk3568-evb1-ddr4-v10.dtsi

&spi0 {

	status = "okay";
	rc522:rc522@0{

        compatible = "rc522";
        reg = <0>;
        spi-max-frequency = <1000000>;
	};
};

图片[1] - RK3568 平台 RC522 RFID 驱动开发全解析 - 宋马
设置一些引脚复用功能
/home/chenmy/rk356x/RK356X_Android11.0/kernel/arch/arm64/boot/dts/rockchip/rk3568.dtsi

	spi0: spi@fe610000 {

		compatible = "rockchip,rk3066-spi";
		reg = <0x0 0xfe610000 0x0 0x1000>;
		interrupts = <GIC_SPI 103 IRQ_TYPE_LEVEL_HIGH>;
		#address-cells = <1>;
		#size-cells = <0>;
		clocks = <&cru CLK_SPI0>, <&cru PCLK_SPI0>;
		clock-names = "spiclk", "apb_pclk";
		dmas = <&dmac0 20>, <&dmac0 21>;
		dma-names = "tx", "rx";
		pinctrl-names = "default", "high_speed";
		//pinctrl-0 = <&spi0m0_cs0 &spi0m0_cs1 &spi0m0_pins>;
		pinctrl-0 = <&spi0m1_cs0 &spi0m1_pins>;
		//pinctrl-1 = <&spi0m0_cs0 &spi0m0_cs1 &spi0m0_pins_hs>;
		pinctrl-1 = <&spi0m1_cs0 &spi0m1_pins_hs>;
		status = "disabled";

	};

图片[2] - RK3568 平台 RC522 RFID 驱动开发全解析 - 宋马
下面这个是系统自带的引脚复用直接使用
/home/chenmy/rk356x/RK356X_Android11.0/kernel/arch/arm64/boot/dts/rockchip/rk3568-pinctrl.dtsi

修改完成后需要编译kernel，烧录boot.img
查看引脚复用

cd /sys/kernel/debug/pinctrl/pinctrl-rockchip-pinctrl
cat pinmux-pins

四、内核驱动开发

RC522一些寄存器设置，可以参考RC522手册
图片[3] - RK3568 平台 RC522 RFID 驱动开发全解析 - 宋马
数据格式
图片[4] - RK3568 平台 RC522 RFID 驱动开发全解析 - 宋马
rc522.c

#include <linux/module.h>
#include <linux/kernel.h>
#include <linux/init.h>
#include <linux/spi/spi.h>
#include <linux/delay.h>
#include <linux/gpio.h>
#include <linux/interrupt.h>
#include <linux/of_gpio.h>
#include <linux/vmalloc.h>
#include <linux/cdev.h>

#include <linux/timer.h>
#include <linux/jiffies.h>

#include <linux/workqueue.h>
//#include <linux/spinlock.h>
#include <linux/mutex.h>

#include "mfrc522.h"


#define MAXRLEN 18

/* 认证参数结构 */
struct rc522_auth {

    uint8_t code;        /* 认证模式(PICC_AUTHENT1A/B) */
    uint8_t block_addr;  /* 块地址 */
    uint8_t key[6];      /* 密钥 */
    uint8_t sid[4];      /* 卡片序列号 */
};


/* RC522设备结构 */
struct rc522_dev {

    struct spi_device *spi;
    struct mutex mutex;
    int irq;
    int reset_gpio;
    //struct gpio_desc *cs_gpio;  /* 片选GPIO描述符 */
    dev_t devt;
    struct cdev cdev;
    struct class *class;
    struct device *device;
    bool card_present;
    uint8_t card_uid[5];
    struct timer_list detect_timer;
    struct work_struct detect_work;  // 工作队列
};


/* 向RC522写寄存器 */
static void rc522_write_reg(struct rc522_dev *dev, u8 reg, u8 value)
{

     /* 拉低片选，选中设备 */
    //gpiod_set_value(dev->cs_gpio, 0);

    u8 buf[2];
    struct spi_message msg;
    struct spi_transfer xfer = {

        .tx_buf = buf,
        .len = 2,
        .cs_change = 0,
    };

    /* 寄存器地址格式: 0XXXXXX0 */
    buf[0] = (reg << 1) & 0x7E;
    buf[1] = value;

    //spi_write(dev->spi, buf, 2);

    spi_message_init(&msg);
    spi_message_add_tail(&xfer, &msg);
    spi_sync(dev->spi, &msg);

    /* 拉高片选，释放设备 */
    //gpiod_set_value(dev->cs_gpio, 1);

}

/* 从RC522读寄存器 */
static u8 rc522_read_reg(struct rc522_dev *dev, u8 reg)
{

     /* 拉低片选，选中设备 */
    //gpiod_set_value(dev->cs_gpio, 0);
    u8 tx_buf[2];
    u8 rx_buf[2];
    struct spi_message msg;
    struct spi_transfer xfer = {

        .tx_buf = tx_buf,
        .rx_buf = rx_buf,
        .len = 2,
        .cs_change = 0,
    };

    /* 寄存器地址格式: 1XXXXXX0 */
    tx_buf[0] = ((reg << 1) & 0x7E) | 0x80;
    tx_buf[1] = 0;

    //spi_write_then_read(dev->spi, tx_buf, 2, rx_buf, 2);

    spi_message_init(&msg);
    spi_message_add_tail(&xfer, &msg);
    spi_sync(dev->spi, &msg);

    /* 拉高片选，释放设备 */
    //gpiod_set_value(dev->cs_gpio, 1);

    return rx_buf[1];
}



/* 设置RC522寄存器的多个位 */
static void rc522_set_bit_mask(struct rc522_dev *dev, u8 reg, u8 mask)
{

    u8 tmp;
    tmp = rc522_read_reg(dev, reg);
    rc522_write_reg(dev, reg, tmp | mask);
}

/* 清除RC522寄存器的多个位 */
static void rc522_clear_bit_mask(struct rc522_dev *dev, u8 reg, u8 mask)
{

    u8 tmp;
    tmp = rc522_read_reg(dev, reg);
    rc522_write_reg(dev, reg, tmp & (~mask));
}

/* 计算CRC校验值 */
static int rc522_calculate_crc(struct rc522_dev *dev, u8 *data, u8 length, u8 *crc)
{

    u8 i;

    /* 清空CRC寄存器 */
    rc522_clear_bit_mask(dev, DivIrqReg, 0x04);    /* 清除CRC中断标志 */
    rc522_write_reg(dev, CommandReg, PCD_IDLE);
    rc522_set_bit_mask(dev, FIFOLevelReg, 0x80);   /* 清空FIFO */

    /* 写入数据 */
    for (i = 0; i < length; i++) {

        rc522_write_reg(dev, FIFODataReg, data[i]);
    }

    /* 启动CRC计算 */
    rc522_write_reg(dev, CommandReg, PCD_CALCCRC);

    /* 等待计算完成 */
    i = 0;
    while (!(rc522_read_reg(dev, DivIrqReg) & 0x04)) {

        i++;
        if (i > 0xFF) return MI_ERR;
        udelay(10);
    }

    /* 读取CRC结果 */
    crc[0] = rc522_read_reg(dev, CRCResultRegL);
    crc[1] = rc522_read_reg(dev, CRCResultRegM);

    return MI_OK;
}

/
//功    能：通过RC522和ISO14443卡通讯
/
static int rc522_transceive(struct rc522_dev *dev, u8 command, u8 *send_data, u8 send_len,
                           u8 *recv_data, u8 *recv_len)
{

    int status = MI_ERR;
    u8 irq_en = 0x00;
    u8 irq_wait = 0x00;
    u8 last_bits;
    u8 n;
    u16 i;
    switch (command)
    {

       case PCD_AUTHENT:
          irq_en   = 0x12;
          irq_wait = 0x10;
          break;
       case PCD_TRANSCEIVE:
          irq_en   = 0x77;
          irq_wait = 0x30;
          break;
       default:
         break;
    }

    rc522_write_reg(dev, ComIEnReg, irq_en | 0x80);
    rc522_clear_bit_mask(dev, ComIrqReg, 0x80);
    rc522_write_reg(dev, CommandReg, PCD_IDLE);
    rc522_set_bit_mask(dev, FIFOLevelReg, 0x80);

    for (i = 0; i < send_len; i++)
    {

        rc522_write_reg(dev, FIFODataReg, send_data[i]);
    }
    rc522_write_reg(dev, CommandReg, command);


    if (command == PCD_TRANSCEIVE)
    {

        rc522_set_bit_mask(dev, BitFramingReg, 0x80);
    }

    i = 600;//根据时钟频率调整，操作M1卡最大等待时间25ms
    do
    {

         n = rc522_read_reg(dev, ComIrqReg);
         i--;
    }
    while ((i != 0) && !(n & 0x01) && !(n & irq_wait));

    rc522_clear_bit_mask(dev, BitFramingReg, 0x80);

    if (i != 0)
    {

         if(!(rc522_read_reg(dev, ErrorReg) & 0x1B))
         {

             status = MI_OK;
             if (n & irq_en & 0x01)
             {

                status = MI_NOTAGERR;
             }
             if (command == PCD_TRANSCEIVE)
             {

               	n = rc522_read_reg(dev, FIFOLevelReg);
              	last_bits = rc522_read_reg(dev, ControlReg) & 0x07;

                if (last_bits)
                {

                    *recv_len = (n - 1) * 8 + last_bits;
                } else {

                    *recv_len = n * 8;
                }

                if (n == 0)
                {

                    n = 1;
                }

                if (n > MAXRLEN)
                {

                    n = MAXRLEN;
                }

                for (i = 0; i < n; i++) {

                    recv_data[i] = rc522_read_reg(dev, FIFODataReg);
                }
            }
         }
         else
         {

            status = MI_ERR;
        }

   }


   rc522_set_bit_mask(dev, ControlReg, 0x80);           // stop timer now
   rc522_write_reg(dev, CommandReg, PCD_IDLE);
   return status;
}


/
//功    能：命令卡片进入休眠状态
//返    回: 成功返回MI_OK
/
static char rc522_halt(struct rc522_dev *dev)
{

    int status;
    u8 unLen;
    u8 buffer[MAXRLEN];

    buffer[0] = PICC_HALT;
    buffer[1] = 0;
    rc522_calculate_crc(dev, buffer, 2, &buffer[2]);

    status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 4, buffer, &unLen);

    return MI_OK;
}

/* 寻卡函数
//参数说明: req_mode:寻卡方式
//                0x52 = 寻感应区内所有符合14443A标准的卡
//                0x26 = 寻未进入休眠状态的卡
//          tag_type：卡片类型代码
//                0x4400 = Mifare_UltraLight
//                0x0400 = Mifare_One(S50)
//                0x0200 = Mifare_One(S70)
//                0x0800 = Mifare_Pro(X)
//                0x4403 = Mifare_DESFire
 */
static int rc522_request(struct rc522_dev *dev, u8 req_mode, u8 *tag_type)
{

   int status;
   u8 unLen;
   u8 buffer[MAXRLEN];

    /* 清空RC522中断标志 */
    rc522_clear_bit_mask(dev, Status2Reg, 0x08);
    rc522_write_reg(dev, BitFramingReg, 0x07);
    rc522_set_bit_mask(dev, TxControlReg, 0x03);

    /* 配置发送数据 */
    buffer[0] = req_mode;

    /* 发送寻卡命令 */
    status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 1, buffer, &unLen);

    if ((status == MI_OK) && (unLen == 0x10)) {

        /* 成功接收到卡类型 */
        tag_type[0] = buffer[0];
        tag_type[1] = buffer[1];
        return MI_OK;
    } else {

        return MI_NOTAGERR;
    }
}
/* 防冲突检测，获取卡片UID

//参数说明: uid:卡片序列号，4字节

 */
static int rc522_anticoll(struct rc522_dev *dev, u8 *uid)
{

    int status;
    unsigned char i, snr_check = 0;
    u8 unLen;
    u8 buffer[MAXRLEN];


    rc522_clear_bit_mask(dev, Status2Reg, 0x08);
    rc522_write_reg(dev, BitFramingReg, 0x00);
    rc522_clear_bit_mask(dev, CollReg,0x80);

    buffer[0] = PICC_ANTICOLL1;
    buffer[1] = 0x20;

    status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 2, buffer, &unLen);

    if (status == MI_OK)
    {

    	 for (i=0; i < 4; i++)
         {

             *(uid + i)  = buffer[i];
             snr_check ^= buffer[i];
         }
         if (snr_check != buffer[i])
         {
               status = MI_ERR;    }
    }

    rc522_set_bit_mask(dev, CollReg, 0x80);
    return status;

}

/* 选择卡片

//参数说明: uid:卡片序列号，4字节

 */
static int rc522_select_tag(struct rc522_dev *dev, u8 *uid)
{

    int status;
    unsigned char i;
    u8 unLen;
    u8 buffer[MAXRLEN];

    buffer[0] = PICC_ANTICOLL1;
    buffer[1] = 0x70;
    buffer[6] = 0;
    for (i=0; i < 4; i++)
    {

    	buffer[i + 2] = *(uid + i);
    	buffer[6]  ^= *(uid + i);
    }
    rc522_calculate_crc(dev, buffer, 7, &buffer[7]);

    rc522_clear_bit_mask(dev, Status2Reg, 0x08);

    status = rc522_transceive(dev, PCD_TRANSCEIVE ,buffer, 9, buffer, &unLen);

    if ((status == MI_OK) && (unLen == 0x18))
    {
               status = MI_OK;  }
    else
    {
               status = MI_ERR;    }

    return status;
}

/* 验证卡片密钥
//参数说明: auth_mode: 密码验证模式
//                 0x60 = 验证A密钥
//                 0x61 = 验证B密钥
//          block_addr：块地址
//          key：密码
//          uid：卡片序列号，4字节

 */
static int rc522_auth(struct rc522_dev *dev, u8 auth_mode, u8 block_addr,
                    u8 *key, u8 *uid)
{

    int status;
    u8 unLen;
    u8 i, buffer[MAXRLEN];

    buffer[0] = auth_mode;
    buffer[1] = block_addr;
    for (i = 0; i < 6; i++)
    {
                buffer[i + 2] = *(key + i);   }
    for (i = 0; i < 6; i++)
    {
                buffer[i + 8] = *(uid + i);   }

    status = rc522_transceive(dev, PCD_AUTHENT, buffer, 12, buffer, &unLen);
    if ((status != MI_OK) || (!(rc522_read_reg(dev, Status2Reg) & 0x08)))
    {
               status = MI_ERR;   }

    return status;
}

/* 读取M1卡一块数据
//参数说明: block_addr：块地址
//         data：读出的数据，16字节

 */
static int rc522_read_block(struct rc522_dev *dev, u8 block_addr, u8 *data)
{

    int status;
    u8 unLen;
    u8 i, buffer[MAXRLEN];

    buffer[0] = PICC_READ;
    buffer[1] = block_addr;
    rc522_calculate_crc(dev, buffer, 2, &buffer[2]);

    status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 4, buffer, &unLen);
    if ((status == MI_OK) && (unLen == 0x90))
    {

        for (i = 0; i < 16; i++)
        {
                *(data + i) = buffer[i];   }
    }
    else
    {
               status = MI_ERR;   }

    return status;
}

/* 写数据到M1卡一块
//参数说明: block_addr：块地址
//         data：写入的数据，16字节

 */
static int rc522_write_block(struct rc522_dev *dev, u8 block_addr, u8 *data)
{

    int status;
    u8 unLen;
    u8 i, buffer[MAXRLEN];

    buffer[0] = PICC_WRITE;
    buffer[1] = block_addr;
    rc522_calculate_crc(dev, buffer, 2, &buffer[2]);

    status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 4, buffer, &unLen);

    if ((status != MI_OK) || (unLen != 4) || ((buffer[0] & 0x0F) != 0x0A))
    {
               status = MI_ERR;   }

    if (status == MI_OK)
    {

        //memcpy(ucComMF522Buf, pData, 16);
        for (i = 0; i < 16; i++)
        {
                buffer[i] = *(data + i);   }
        rc522_calculate_crc(dev, buffer, 16, &buffer[16]);

        status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 18, buffer, &unLen);
        if ((status != MI_OK) || (unLen != 4) || ((buffer[0] & 0x0F) != 0x0A))
        {
               status = MI_ERR;   }
    }

    return status;

}

/
//功    能：扣款和充值
//参数说明: dd_mode：命令字
//               0xC0 = 扣款
//               0xC1 = 充值
//          block_addr：钱包地址
//          value：4字节增(减)值，低位在前
//返    回: 成功返回MI_OK
/
static int rc522_decrement_or_increment(struct rc522_dev *dev, u8 dd_mode, u8 block_addr, u8 *value)
{

    int status;
    u8 unLen;
    u8 i, buffer[MAXRLEN];

    buffer[0] = dd_mode;
    buffer[1] = block_addr;
    rc522_calculate_crc(dev, buffer, 2, &buffer[2]);

    status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 4, buffer, &unLen);

    if ((status != MI_OK) || (unLen != 4) || ((buffer[0] & 0x0F) != 0x0A))
    {
               status = MI_ERR;   }

    if (status == MI_OK)
    {

        for (i = 0; i < 16; i++)
        {
                buffer[i] = *(value + i);   }
        rc522_calculate_crc(dev, buffer, 4, &buffer[4]);
        unLen = 0;
        status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 6, buffer, &unLen);
        if (status != MI_ERR)
        {
                status = MI_OK;    }
    }

    if (status == MI_OK)
    {

        buffer[0] = PICC_TRANSFER;
        buffer[1] = block_addr;
        rc522_calculate_crc(dev, buffer, 2, &buffer[2]);

        status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 4, buffer, &unLen);

        if ((status != MI_OK) || (unLen != 4) || ((buffer[0] & 0x0F) != 0x0A))
        {
               status = MI_ERR;   }
    }
    return status;

}

/
//功    能：备份钱包
//参数说明: src_addr：源地址
//          dst_addr：目标地址
//返    回: 成功返回MI_OK
/
static int rc522_bak(struct rc522_dev *dev, unsigned char src_addr, unsigned char dst_addr)
{

    int status;
    u8 unLen;
    u8 buffer[MAXRLEN];

    buffer[0] = PICC_RESTORE;
    buffer[1] = src_addr;
    rc522_calculate_crc(dev, buffer, 2, &buffer[2]);

    status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 4, buffer, &unLen);

    if ((status != MI_OK) || (unLen != 4) || ((buffer[0] & 0x0F) != 0x0A))
    {
               status = MI_ERR;   }

    if (status == MI_OK)
    {

        buffer[0] = 0;
        buffer[1] = 0;
        buffer[2] = 0;
        buffer[3] = 0;
        rc522_calculate_crc(dev, buffer, 4, &buffer[4]);

        status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 6, buffer, &unLen);
        if (status != MI_ERR)
        {
                status = MI_OK;    }
    }

    if (status != MI_OK)
    {
                return MI_ERR;   }

    buffer[0] = PICC_TRANSFER;
    buffer[1] = dst_addr;

    rc522_calculate_crc(dev, buffer, 2, &buffer[2]);

    status = rc522_transceive(dev, PCD_TRANSCEIVE, buffer, 4, buffer, &unLen);

    if ((status != MI_OK) || (unLen != 4) || ((buffer[0] & 0x0F) != 0x0A))
    {
               status = MI_ERR;   }

    return status;
}








/* 复位RC522 */
static void rc522_reset(struct rc522_dev *dev)
{

    /* 硬件复位 */
    if (dev->reset_gpio >= 0) {

        gpio_set_value(dev->reset_gpio, 0);
        msleep(10);
        gpio_set_value(dev->reset_gpio, 1);
        msleep(10);
    }

    /* 软件复位 */
    rc522_write_reg(dev, CommandReg, PCD_RESETPHASE);

    msleep(5);

    /* 配置RC522 */
    rc522_write_reg(dev, ModeReg, 0x3D);          /* 和Mifare卡通讯，CRC初始值0x6363 */
    rc522_write_reg(dev, TReloadRegL, 30);
    rc522_write_reg(dev, TReloadRegH, 0);
    rc522_write_reg(dev, TModeReg, 0x8D);
    rc522_write_reg(dev, TPrescalerReg, 0x3E);
    rc522_write_reg(dev, TxAutoReg, 0x40);

    u8 value = rc522_read_reg(dev, TxAutoReg);
    printk(KERN_INFO " rc522_reset TxAutoReg value = %d
", value);
}


/
//开启天线
//每次启动或关闭天险发射之间应至少有1ms的间隔
/
static void rc522_antenna_on(struct rc522_dev *dev)
{

    unsigned char i;
    i = rc522_read_reg(dev, TxControlReg);

    if (!(i & 0x03))
    {

        rc522_set_bit_mask(dev, TxControlReg, 0x03);
    }

    printk(KERN_INFO " rc522_antenna_on i = %d
", i);
}


/
//关闭天线
/
static void rc522_antenna_off(struct rc522_dev *dev)
{

    rc522_clear_bit_mask(dev, TxControlReg, 0x03);
    printk(KERN_INFO " rc522_antenna_off
");
}


/* 文件操作：打开设备 */
static int rc522_open(struct inode *inode, struct file *filp)
{

    struct rc522_dev *dev = container_of(inode->i_cdev, struct rc522_dev, cdev);
    filp->private_data = dev;


    return 0;
}

/* 文件操作：释放设备 */
static int rc522_release(struct inode *inode, struct file *filp)
{

    return 0;
}

/* 文件操作：IOCTL控制 */
static long rc522_ioctl(struct file *filp, unsigned int cmd, unsigned long arg)
{

    return 0;
}

/* 文件操作表 */
static const struct file_operations rc522_fops = {

    .owner = THIS_MODULE,
    .open = rc522_open,
    .release = rc522_release,
    .unlocked_ioctl = rc522_ioctl,
};
static unsigned char g_ucTempbuf[20];

unsigned char data1[16] = {
            0x12,0x34,0x56,0x78,0xED,0xCB,0xA9,0x87,0x12,0x34,0x56,0x78,0x01,0xFE,0x01,0xFE};
//M1卡的某一块写为如下格式，则该块为钱包，可接收扣款和充值命令
//4字节金额（低字节在前）＋4字节金额取反＋4字节金额＋1字节块地址＋1字节块地址取反＋1字节块地址＋1字节块地址取反
unsigned char data2[4]  = {
            0x12,0,0,0};
unsigned char DefaultKey[6] = {
            0xFF, 0xFF, 0xFF, 0xFF, 0xFF, 0xFF};


/* 工作队列处理函数 - 可以安全休眠 */
static void rc522_detect_work(struct work_struct *work)
{

    struct rc522_dev *dev = container_of(work, struct rc522_dev, detect_work);
    u8 tag_type[2];
    int status, i;
    memset(g_ucTempbuf, 0, 20);

    // 使用mutex保护共享资源
    mutex_lock(&dev->mutex);

    status = rc522_request(dev, PICC_REQALL, tag_type);
    if (status == MI_OK) {

        dev_info(&dev->spi->dev, "rc522_detect_work Card detected");

        status = rc522_anticoll(dev, g_ucTempbuf);
        if (status != MI_OK)
        {

            printk(KERN_INFO " rc522_detect_work Failed to rc522_anticoll status = %d
", status);
            rc522_halt(dev);
            goto end;
        }

        status = rc522_select_tag(dev, g_ucTempbuf);
        if (status != MI_OK)
        {

            printk(KERN_INFO " rc522_detect_work Failed to rc522_select_tag status = %d
", status);
            goto end;
        }

        status = rc522_auth(dev, PICC_AUTHENT1A, 1, DefaultKey, g_ucTempbuf);
        if (status != MI_OK)
        {

            printk(KERN_INFO " rc522_detect_work Failed to rc522_auth status = %d
", status);
            goto end;
        }
        printk(KERN_INFO "rc522_detect_work The Card ID is: %02X%02X%02X%02X",g_ucTempbuf[0], g_ucTempbuf[1], g_ucTempbuf[2],g_ucTempbuf[3]);

        status = rc522_write_block(dev, 1, data1);
        if (status != MI_OK)
        {

            printk(KERN_INFO " rc522_detect_work Failed to rc522_write_block status = %d
", status);
            goto end;
        }
        /*
        status = rc522_decrement_or_increment(dev, PICC_DECREMENT, 1, data2);
        if (status != MI_OK)
        {
            printk(KERN_INFO " rc522_detect_work Failed to rc522_decrement_or_increment status = %d
", status);
            goto end;
        }
        */
        status = rc522_read_block(dev, 2, g_ucTempbuf);
        if (status != MI_OK)
        {

            printk(KERN_INFO " rc522_detect_work Failed to rc522_read_block status = %d
", status);
            goto end;
        }

    } else {

        dev_info(&dev->spi->dev, "rc522_detect_work Card removed");
    }
end:
    mutex_unlock(&dev->mutex);
}

/* 定时器回调 - 原子上下文，快速返回 */
static void rc522_detect_timer(struct timer_list *t)
{

    struct rc522_dev *dev = from_timer(dev, t, detect_timer);


    // 调度工作队列处理耗时操作
    schedule_work(&dev->detect_work);

    // 重新启动定时器，继续周期性检测
    mod_timer(&dev->detect_timer, jiffies + msecs_to_jiffies(1000));  // 1000ms后再次触发
}

/* 初始化定时器 */
static int rc522_init_timer(struct rc522_dev *dev)
{


    rc522_reset(dev);
    rc522_antenna_off(dev);
    /*rc522_clear_bit_mask(dev, Status2Reg, 0x08);
    rc522_write_reg(dev, ModeReg, 0x3D);         //3F
    rc522_write_reg(dev, RxSelReg, 0x86);        //84
    rc522_write_reg(dev, RFCfgReg, 0x7F);         //4F
    rc522_write_reg(dev, TReloadRegL, 30);
    rc522_write_reg(dev, TReloadRegH, 0);
    rc522_write_reg(dev, TModeReg, 0x8D);
    rc522_write_reg(dev, TPrescalerReg, 0x3E); */
    msleep(100);
    rc522_antenna_on(dev);
    int ret = rc522_read_reg(dev, ModeReg);
    printk(KERN_INFO " rc522_init_timer ModeReg = %d
", ret);


    // 初始化工作队列
    INIT_WORK(&dev->detect_work, rc522_detect_work);

    // 初始化定时器
    timer_setup(&dev->detect_timer, rc522_detect_timer, 0);

    mod_timer(&dev->detect_timer, jiffies + msecs_to_jiffies(500));

    return 0;
}

/* 释放定时器 */
static void rc522_release_timer(struct rc522_dev *dev)
{


    del_timer_sync(&dev->detect_timer);
    cancel_work_sync(&dev->detect_work);
}


/* 初始化RC522设备 */
static int rc522_probe(struct spi_device *spi)
{

    struct rc522_dev *dev;
    int ret;

    /* 分配设备结构体 */
    dev = devm_kzalloc(&spi->dev, sizeof(*dev), GFP_KERNEL);
    if (!dev) {

        dev_err(&spi->dev, "rc522_probe Failed to allocate memory for device
");
        return -ENOMEM;
    }

    dev->spi = spi;
    mutex_init(&dev->mutex);
    dev->card_present = false;

    /* 设置SPI模式 */
    spi->mode = /*SPI_MODE_0 | SPI_CS_HIGH*/SPI_MODE_0;
    printk(KERN_INFO " rc522_init_timer spi->mode = %d
", spi->mode);
    spi->bits_per_word = 8;
    spi->max_speed_hz = 1000000;  /* 1MHz */
    ret = spi_setup(spi);
    if (ret) {

        dev_err(&spi->dev, "rc522_probe Failed to setup SPI device: %d
", ret);
        return ret;
    }


    /* 分配字符设备号 */
    ret = alloc_chrdev_region(&dev->devt, 0, 1, "rc522");
    if (ret < 0) {

        dev_err(&spi->dev, "rc522_probe Failed to allocate char device region
");
        return ret;
    }

    /* 初始化字符设备 */
    cdev_init(&dev->cdev, &rc522_fops);
    dev->cdev.owner = THIS_MODULE;
    ret = cdev_add(&dev->cdev, dev->devt, 1);
    if (ret) {

        dev_err(&spi->dev, "rc522_probe Failed to add char device
");
        unregister_chrdev_region(dev->devt, 1);
        return ret;
    }
    dev->reset_gpio = -1;

     /* 获取片选GPIO */
    /*dev->cs_gpio = devm_gpiod_get(&spi->dev, "cs", GPIOD_OUT_HIGH);
    if (IS_ERR(dev->cs_gpio)) {
        dev_err(&spi->dev, "Failed to get CS GPIO
");
        return PTR_ERR(dev->cs_gpio);
    }*/

    /* 创建类 */
    dev->class = class_create(THIS_MODULE, "rc522");
    if (IS_ERR(dev->class)) {

        dev_err(&spi->dev, "rc522_probe Failed to create class
");
        cdev_del(&dev->cdev);
        unregister_chrdev_region(dev->devt, 1);
        return PTR_ERR(dev->class);
    }

    /* 创建设备节点 */
    dev->device = device_create(dev->class, NULL, dev->devt, NULL, "rc522");
    if (IS_ERR(dev->device)) {

        dev_err(&spi->dev, "rc522_probe Failed to create device
");
        class_destroy(dev->class);
        cdev_del(&dev->cdev);
        unregister_chrdev_region(dev->devt, 1);
        return PTR_ERR(dev->device);
    }

    /* 保存设备结构体指针 */
    spi_set_drvdata(spi, dev);

    rc522_init_timer(dev);



    dev_info(&spi->dev, "rc522_probe RC522 RFID device initialized
");
    return 0;
}

/* 移除RC522设备 */
static int rc522_remove(struct spi_device *spi)
{

    struct rc522_dev *dev = spi_get_drvdata(spi);

    // 释放定时器
    rc522_release_timer(dev);

    device_destroy(dev->class, dev->devt);
    class_destroy(dev->class);
    cdev_del(&dev->cdev);
    unregister_chrdev_region(dev->devt, 1);

    dev_info(&spi->dev, "RC522 RFID device removed
");
    return 0;
}


/* 设备树匹配表 */
static const struct of_device_id rc522_of_match[] = {

    {
             .compatible = "rc522" },
    {
             }
};
MODULE_DEVICE_TABLE(of, rc522_of_match);

/* SPI驱动结构体 */
static struct spi_driver rc522_driver = {

    .driver = {

        .name = "rc522",
        .owner = THIS_MODULE,
        .of_match_table = rc522_of_match,
    },
    .probe = rc522_probe,
    .remove = rc522_remove,
};

/* 模块初始化函数 */
static int __init rc522_init_module(void)
{

    int ret;
    ret = spi_register_driver(&rc522_driver);
    if (ret) {

        printk(KERN_ERR "rc522_init_module Failed to register RC522 SPI driver
");
        return ret;
    }
    printk(KERN_INFO "rc522_init_module RC522 SPI driver registered
");
    return 0;
}

/* 模块退出函数 */
static void __exit rc522_exit_module(void)
{

    spi_unregister_driver(&rc522_driver);
    printk(KERN_INFO "rc522_exit_module RC522 SPI driver unregistered
");
}

module_init(rc522_init_module);
module_exit(rc522_exit_module);


MODULE_LICENSE("GPL");
MODULE_DESCRIPTION("RC522 RFID Reader Driver");
MODULE_AUTHOR("cmy");

rc522.h


/
//MF522命令字
/
#define PCD_IDLE              0x00               //取消当前命令
#define PCD_AUTHENT           0x0E               //验证密钥
#define PCD_RECEIVE           0x08               //接收数据
#define PCD_TRANSMIT          0x04               //发送数据
#define PCD_TRANSCEIVE        0x0C               //发送并接收数据
#define PCD_RESETPHASE        0x0F               //复位
#define PCD_CALCCRC           0x03               //CRC计算

/
//Mifare_One卡片命令字
/
#define PICC_REQIDL           0x26               //寻天线区内未进入休眠状态
#define PICC_REQALL           0x52               //寻天线区内全部卡
#define PICC_ANTICOLL1        0x93               //防冲撞
#define PICC_ANTICOLL2        0x95               //防冲撞
#define PICC_AUTHENT1A        0x60               //验证A密钥
#define PICC_AUTHENT1B        0x61               //验证B密钥
#define PICC_READ             0x30               //读块
#define PICC_WRITE            0xA0               //写块
#define PICC_DECREMENT        0xC0               //扣款
#define PICC_INCREMENT        0xC1               //充值
#define PICC_RESTORE          0xC2               //调块数据到缓冲区
#define PICC_TRANSFER         0xB0               //保存缓冲区中数据
#define PICC_HALT             0x50               //休眠

/
//MF522 FIFO长度定义
/
#define DEF_FIFO_LENGTH       64                 //FIFO size=64byte

/
//MF522寄存器定义
/
// PAGE 0
#define     RFU00                 0x00
#define     CommandReg            0x01
#define     ComIEnReg             0x02
#define     DivlEnReg             0x03
#define     ComIrqReg             0x04
#define     DivIrqReg             0x05
#define     ErrorReg              0x06
#define     Status1Reg            0x07
#define     Status2Reg            0x08
#define     FIFODataReg           0x09
#define     FIFOLevelReg          0x0A
#define     WaterLevelReg         0x0B
#define     ControlReg            0x0C
#define     BitFramingReg         0x0D
#define     CollReg               0x0E
#define     RFU0F                 0x0F
// PAGE 1
#define     RFU10                 0x10
#define     ModeReg               0x11
#define     TxModeReg             0x12
#define     RxModeReg             0x13
#define     TxControlReg          0x14
#define     TxAutoReg             0x15
#define     TxSelReg              0x16
#define     RxSelReg              0x17
#define     RxThresholdReg        0x18
#define     DemodReg              0x19
#define     RFU1A                 0x1A
#define     RFU1B                 0x1B
#define     MifareReg             0x1C
#define     RFU1D                 0x1D
#define     RFU1E                 0x1E
#define     SerialSpeedReg        0x1F
// PAGE 2
#define     RFU20                 0x20
#define     CRCResultRegM         0x21
#define     CRCResultRegL         0x22
#define     RFU23                 0x23
#define     ModWidthReg           0x24
#define     RFU25                 0x25
#define     RFCfgReg              0x26
#define     GsNReg                0x27
#define     CWGsCfgReg            0x28
#define     ModGsCfgReg           0x29
#define     TModeReg              0x2A
#define     TPrescalerReg         0x2B
#define     TReloadRegH           0x2C
#define     TReloadRegL           0x2D
#define     TCounterValueRegH     0x2E
#define     TCounterValueRegL     0x2F
// PAGE 3
#define     RFU30                 0x30
#define     TestSel1Reg           0x31
#define     TestSel2Reg           0x32
#define     TestPinEnReg          0x33
#define     TestPinValueReg       0x34
#define     TestBusReg            0x35
#define     AutoTestReg           0x36
#define     VersionReg            0x37
#define     AnalogTestReg         0x38
#define     TestDAC1Reg           0x39
#define     TestDAC2Reg           0x3A
#define     TestADCReg            0x3B
#define     RFU3C                 0x3C
#define     RFU3D                 0x3D
#define     RFU3E                 0x3E
#define     RFU3F		  0x3F

/
//和MF522通讯时返回的错误代码
/
#define MI_OK                          0
#define MI_NOTAGERR                    (-1)
#define MI_ERR                         (-2)

Makefile

export ARCH=arm64

export CROSS_COMPILE=/home/chenmy/rk356x/RK356X_Android11.0/prebuilts/gcc/linux-x86/aarch64/gcc-linaro-6.3.1-2017.05-x86_64_aarch64-linux-gnu/bin/aarch64-linux-gnu-

obj-m += rc522.o

KERNEL_DIR:=/home/chenmy/rk356x/RK356X_Android11.0/kernel

all:
	make -C $(KERNEL_DIR) M=$(PWD) modules
clean:
	make -C $(KERNEL_DIR) M=$(PWD) clean

五、调试与验证

将编译好的rc522.ko拷贝到开发板

图片[5] - RK3568 平台 RC522 RFID 驱动开发全解析 - 宋马
可以看到能够成功的读取的ic卡的信息了。
通过读取寄存器的取值来判断是否写入成功。

六、参考资料

1.RC522 数据手册
2.RK3568 芯片手册
3.Linux 内核文档
4.SPI 子系统文档
5.Linux 设备树参考指南
6.RC522芯片提供的51单片机程序

© 版权声明
文章版权归作者所有，未经允许请勿转载。如内容涉嫌侵权，请在本页底部进入<联系我们>进行举报投诉!
THE END
知识分享
如果内容对您有所帮助,就支持一下吧!
点赞0 分享
上海信世展览的头像 - 宋马
2025电脑游戏推荐：从3A大作到免费精品，总有一款让你欲罢不能 - 宋马
2025电脑游戏推荐：从3A大作到免费精品，总有一款让你欲罢不能
2025电脑游戏推荐：从3A大作到免费精品，总有一款让你欲罢不能
6个月前 52
随机更换电脑壁纸小工具V2.0.0 - 宋马
随机更换电脑壁纸小工具V2.0.0
随机更换电脑壁纸小工具V2.0.0
5个月前 51
Apple Watch 界面大改，绝了！ - 宋马
Apple Watch 界面大改，绝了！
Apple Watch 界面大改，绝了！
2个月前 22
Linux环境中的date命令使用技巧 - 宋马
Linux环境中的date命令使用技巧
Linux环境中的date命令使用技巧
4个月前 13
生态系统是理解大自然的核心概念 - 宋马
生态系统是理解大自然的核心概念
生态系统是理解大自然的核心概念
6个月前 11
使用PIN码保护你的文档 - 宋马
使用PIN码保护你的文档
使用PIN码保护你的文档
4个月前 8
随机推荐
最新发布||甘肃高院、甘肃省公安厅联合印发2023年甘肃省道路交通事故人身损害赔偿有关费用计算标准 - 宋马
最新发布||甘肃高院、甘肃省公安厅联合印发2023年甘肃省道路交通事故人身损害赔偿有关费用计算标准
最新发布||甘肃高院、甘肃省公安厅联合印发2023年甘肃省道路交通事故人身损害赔偿有关费用计算标...
6个月前 13
《考试脑科学3》，副标题叫“打开学习动力的‘脑开关’” - 宋马
《考试脑科学3》，副标题叫“打开学习动力的‘脑开关’”
《考试脑科学3》，副标题叫“打开学习动力的‘脑开关’”
1个月前 10
一种StartisBack运行错误的补救办法 - 宋马
一种StartisBack运行错误的补救办法
一种StartisBack运行错误的补救办法
5个月前 28
SpannableStringBuilder为文本设置不同字体大小，颜色等样式 - 宋马
SpannableStringBuilder为文本设置不同字体大小，颜色等样式
SpannableStringBuilder为文本设置不同字体大小，颜色等样式
3个月前 7
火狐老是弹出下载openh264-win32-….zip - 宋马
火狐老是弹出下载openh264-win32-….zip
火狐老是弹出下载openh264-win32-….zip
3个月前 10
微信小程序入门1 - 宋马
微信小程序入门1
微信小程序入门1
6个月前 46
评论 抢沙发

请登录后发表评论

    暂无评论内容

用户封面
上海信世展览的头像 - 宋马
随机更换电脑壁纸小工具V2.0.0
Apple Watch 界面大改，绝了！
使用PIN码保护你的文档
2025电脑游戏推荐：从3A大作到免费精品，总有一款让你欲罢不能
Linux环境中的date命令使用技巧
生态系统是理解大自然的核心概念
3个方法，教你如何设置 Windows 10/11 自动登录，一键直达桌面 - 宋马
1.2W+人已阅读
3个方法，教你如何设置 Windows 10/11 自动登录，一键直达桌面
TOP1
(番外)+(全文)李福海宋观潮：结局+全文+后续(李福海宋观潮)小说最新列表_官途风云李福海宋观潮：结局+全文+后续(李福海宋观潮)全文阅读无弹窗初官途风云：结局+全文+后续 - 宋马
(番外)+(全文)李福海宋观潮：结局+全文+后续(李福海宋观潮)小说最新列表_官途风云李福海宋观潮：结局+全文+后续(李福海宋观潮)全文阅读无弹窗初官途风云：结局+全文+后续
6个月前4258人已阅读
TOP2
热门视频《bj女团熊猫班全员卸甲》免费观看_《bj女团熊猫班全员卸甲》无删减版 HD 高清在线观看_《bj女团熊猫班全员卸甲》全集免费观看，《bj女团熊猫班全员卸甲》全集在线播放 - 西瓜影视网... - 宋马
热门视频《bj女团熊猫班全员卸甲》免费观看_《bj女团熊猫班全员卸甲》无删减版 HD 高清在线观看_《bj女团熊猫班全员卸甲》全集免费观看，《bj女团熊猫班全员卸甲》全集在线播放 – 西瓜影视网…
1个月前4133人已阅读
TOP3
QQ小世界突然消失！3亿用户炸锅：我的青春视频被一键清空了？ - 宋马
QQ小世界突然消失！3亿用户炸锅：我的青春视频被一键清空了？
5个月前3430人已阅读
TOP4
玩客云/网心云刷OpenWrt当旁路由教程 - 宋马
玩客云/网心云刷OpenWrt当旁路由教程
4个月前3035人已阅读
TOP5
最新困困兔宿舍录屏视频在线观看_宿舍直播回放完整版_高清原版网盘资源下载即点即看 - 宋马
最新困困兔宿舍录屏视频在线观看_宿舍直播回放完整版_高清原版网盘资源下载即点即看
1个月前2413人已阅读
TOP6
TOP1
TOP2
TOP3
TOP4
TOP5
TOP6
3个方法，教你如何设置 Windows 10/11 自动登录，一键直达桌面 - 宋马

3个方法，教你如何设置 Windows 10/11 自动登录，一键直达桌面

知识分享
般若如花的头像 - 宋马8个月前
41.2W+1
(番外)+(全文)李福海宋观潮：结局+全文+后续(李福海宋观潮)小说最新列表_官途风云李福海宋观潮：结局+全文+后续(李福海宋观潮)全文阅读无弹窗初官途风云：结局+全文+后续 - 宋马

(番外)+(全文)李福海宋观潮：结局+全文+后续(李福海宋观潮)小说最新列表_官途风云李福海宋观潮：结局+全文+后续(李福海宋观潮)全文阅读无弹窗初官途风云：结局+全文+后续

知识分享
会飞的龙的头像 - 宋马6个月前
042582
热门视频《bj女团熊猫班全员卸甲》免费观看_《bj女团熊猫班全员卸甲》无删减版 HD 高清在线观看_《bj女团熊猫班全员卸甲》全集免费观看，《bj女团熊猫班全员卸甲》全集在线播放 - 西瓜影视网... - 宋马

热门视频《bj女团熊猫班全员卸甲》免费观看_《bj女团熊猫班全员卸甲》无删减版 HD 高清在线观看_《bj女团熊猫班全员卸甲》全集免费观看，《bj女团熊猫班全员卸甲》全集在线播放 – 西瓜影视网…

知识分享
有梗回复的头像 - 宋马1个月前
041331
QQ小世界突然消失！3亿用户炸锅：我的青春视频被一键清空了？ - 宋马

QQ小世界突然消失！3亿用户炸锅：我的青春视频被一键清空了？

知识分享
我的云小姐的头像 - 宋马5个月前
234301
玩客云/网心云刷OpenWrt当旁路由教程 - 宋马

玩客云/网心云刷OpenWrt当旁路由教程

知识分享
多读书涨智慧的头像 - 宋马4个月前
030352
最新困困兔宿舍录屏视频在线观看_宿舍直播回放完整版_高清原版网盘资源下载即点即看 - 宋马

最新困困兔宿舍录屏视频在线观看_宿舍直播回放完整版_高清原版网盘资源下载即点即看

知识分享
轨迹的头像 - 宋马1个月前
024130
龚成思龙门县龙辉龙泉站龙族前传龙口市忠证基因龙口市亲子鉴定齐玉苓案鼻血的教训鼓励非公有制经济黔东南亲子鉴定机构黔东南亲子鉴定中心黔东南亲子鉴定黑龙江省长黑龙江省教育厅厅长黑龙江省司法厅黑话律师黑袍纠察队黑暗转向黑暗荣耀
